Absorbers

Absorber panels are used on walls, ceilings or suspended within a  room to control noise energy and reverberation.  Essi absorber panels  are constructed from rigid glass fiber board available standard in a  wide range of thicknesses to provide the correct absorption product for  your project.  Optional impact tackable surfaces, edge details, standard  and custom finishes insure no sacrifice to aesthetics or function.   Essi also has specially designed absorber panels to perform specific  sound deadening tasks.  A variety of available mountings allow  installation virtually anywhere within the room.



 Model: 500
Core: Fiberglass Absorber Panel
Finishes: Fabric or Perforated Vinyl Wallcovering
Sizes: Up to 4' x 10'
Mounting: Adhesive, Impale Clips, 2-Part Z Clips. Click here to see pictures.
Thickness: 2" (.95 NRC)
Density: 6-7 pounds per cubic foot
Edges: Chemically Hardened (square, beveled, radius, mitered). Click here to see pictures.
Flammability: Class "A" per ASTM E84
Mounting Surface: Vertical
Application: 500 Hertz Absorber Panel
Product Type: Absorber - Interactive Absorber or DiffuserWall Panel




These waterproof, interactive baffles are perfect for indoor play area sound deadening or even reducing kennel reverberation.

Model: B-150
Core: Vertical Ceiling Baffle
Finishes: Class "A" 3.0 mil. PVC
Sizes: 2' x 4'
Mounting: Grommet
Thickness: 1-1/2" (1.0 sabin per square foot)
Density: 1.5 pounds per cubic foot
Edges: Untreated Square
Flammability: Class "A" per ASTM E84
Mounting Surface: Vertical from Ceiling
Application: Ceiling
Product Type: Absorber - Baffle - Interactive Absorber or Diffuser





These large waterproof and interactive noise baffles can provide sound masking for environments with children and animals.

Model: B-200
Core: Vertical Ceiling Baffle
Finishes: Class "A" 3.0 mil. PVC
Sizes: Up to 4' 8'
Mounting: Grommet
Thickness: 1-1/2" (1.0 sabin per square foot)
Density: 3.0 pounds per square foot
Edges: Untreated Square
Flammability: Class "A" per ASTM E84
Mounting Surface: Vertical from Ceiling
Application: Ceiling
Product Type: Absorber - Baffle - Ceiling Panel - Interactive Absorber or Diffuser




 Model: LFA
Core: Low Frequency Fiberglass Absorber Panel
Finishes: Fabric or Perforated Vinyl Wallcovering
Sizes: Up to 4' by 10'
Mounting: Adhesive, Impale Clips, 2-Part Z Clips.
Thickness: 2"
Density: 6-7 pounds per cubic foot
Edges: Chemically Hardened Square
Flammability: Class "A" per ASTM E84
Mounting Surface: Vertical or Horizontal
Application: Low Frequency Absorber Panel
Product Type: Absorber - Ceiling Panel - Interactive Absorber or Diffuser - Wall Panel



 Model: MFA
Core: Mid Frequency Fiberglass Absorber Panel
Finishes: Fabric or Perforated Vinyl Wallcovering
Sizes: Up to 4' by 8'
Mounting: Adhesive, Impale Clips, 2-Part Z Clips.
Thickness: 2" (.65 NRC)
Density: 3.0 pounds per cubic foot
Edges: Galvanized Steel (square)
Flammability: Class "A" per ASTM E84
Mounting Surface: Vertical
Application: Steel Edged Mid Frequency Absorber Panel
Product Type: Absorber - Interactive Absorber or Diffuser - Wall Panel




Model: W-101
Core: Resilient Fiberglass Absorber Panel
Finishes: Hytex Ribbed Fabric
Sizes: Up to 4’ x 10’
Mounting: Adhesive, Screw & Washer.
Thickness: 1” (.80 NRC) 1-1/2” (.90 NRC) 2” (1.05 NRC)
Density: 6-7 pounds per cubic foot
Edges: Resilient (square, beveled).
Flammability: Class “A” per ASTM E84
Mounting Surface: Vertical or Horizontal
Application: Gymnasium
Product Type: Absorber - Ceiling Panel - Interactive Absorber or Diffuser - Wall Panel




 Model: W-103
Core: Fiberglass
Finishes: Fabric or Perforated Vinyl Wall Covering
Sizes: 1"
Mounting: Impale Clips, 2-Part Z Clips.
Thickness: 1"
Density: 6lb
Edges: Galvanized Square Edge
Flammability: Class A
Mounting Surface: Vertical or Horizontal
Application: Steel Edged Basic Absorber Panel
Product Type: Absorber - Ceiling Panel - Interactive Absorber or Diffuser - Wall Panel




Model: W-104
Core: Impact Tackable Fiberglass Absorber Panel
Finishes: Fabric or Perforated Vinyl Wallcovering
Sizes: Up to 5’ x 10’
Mounting: Adhesive, Impale Clips, 2-Part Z Clips.
Thickness: 1-1/8” (.85 NRC) 1-5/8” (.90 NRC) 2-1/8” (1.05 NRC) 3-1/8” (1.10 NRC) 4-1/8” (1.10 NRC)
Density: 6-7 pounds per cubic foot with 1/8”, 16 to 18 pounds per cubic foot face layer.
Edges: Galvanized Steel (square)
Flammability: Class “A” per ASTM E84
Mounting Surface: Vertical or Horizontal
Application: Steel Edged Impact Tackable Absorber Panel
Product Type: Absorber - Ceiling Panel - Interactive Absorber or Diffuser - Wall Panel





Model: W-105

Core: Tackable Mineral Board Panel

Finishes: Fabric or Vinyl Wallcovering

Sizes: Up to 4’ x 10’

Mounting: Adhesive, Impale Clips, 2-Part Z Clips.

Thickness: 1/2” (.50 NRC) 3/4” (.60 NRC)

Density: 18 to 24 pounds per cubic foot

Edges: Untreated (square, beveled, radius).

Flammability: Class “A” per ASTM E84

Mounting Surface: Vertical

Application: Basic Tackable Panel

Product Type: Absorber - Interactive - Absorber or Diffuser - Wall Panel





Model: W-106
Core: Fiberglass Absorber Panel
Finishes: Fabric or Perforated Vinyl Wallcovering
Sizes: Up to 4’ x 10’
Mounting: Adhesive, Impale Clips, 2-Part Z Clips.
Thickness: 1” (.80 NRC) 1-1/2” (.90 NRC) 2” (1.05 NRC) 3” (1.10 NRC) 4” (1.10 NRC)
Density: 6-7 pounds per cubic foot
Edges: Chemically Hardened (square, beveled, radius, mitered).
Flammability: Class "A" per ASTM E84
Mounting Surface: Vertical or Horizontal
Application: Basic Absorber Panel
Product Type: Absorber - Ceiling Panel - Interactive Absorber or Diffuser - Wall Panel





Model: W-107 Ultra
Core: Ultra Impact Fiberglass Absorber Panel (1/16 or 1/8” Perforated Co-Polymer Face)
Finishes: Fabric or Perforated Vinyl Wallcovering
Sizes: Up to 4' x 10'
Mounting: Adhesive, Impale Clips, 2-Part Z Clips.
Thickness: 1-1/8” (.80 NRC) 1-5/8” (.90 NRC) 2-1/8” (1.05 NRC) 3-1/8” (1.10 NRC) 4-1/8” (1.10 NRC) 1-1/16” 1-9/16” 2-1/16” 3-1/16” 4-1/16”
Density: 6-7 pounds per cubic foot with 1/16” or 1/8” Perforated Co-polymer face layer.
Edges: All Eighth Inch - Chemically Hardened (square). Sixteenth Inch - All Edge Options
Flammability: Class "A" per ASTM E84
Mounting Surface: Vertical or Horizontal
Application: Ultra Impact Absorber Panel
Product Type: Absorber - Ceiling Panel - Interactive Absorber or Diffuser - Wall Panel





Optional Back Cut Panels:
Available on the Model  W-107 is a series of cuts on the backside of the panel which create a  flexible panel that will conform to radius or curved surfaces to a  minimum of a 4 foot radius. The spacing and depth of the cuts determine  the flexibility of the panel. The radius dimension is required when  ordering panels with this option.

Model: W-107
Core: Impact Tackable Fiberglass Absorber Panel
Finishes: Fabric or Perforated Vinyl Wallcovering
Sizes: Up to 5’ x 10’
Mounting: Adhesive, Impale Clips, 2-Part Z Clips.
Thickness: 1-1/8” (.85 NRC) 1-5/8” (.90 NRC) 2-1/8” (1.05 NRC) 3-1/8” (1.10 NRC) 4-1/8” (1.10 NRC)
Density: 6-7 pounds per cubic foot with 1/8”, 16 to 18 pounds per cubic foot face layer.
Edges: Chemically Hardened (square, beveled, radius, mitered).
Flammability: Class "A" per ASTM E84
Mounting Surface: Vertical or Horizontal
Application: Impact Tackable Absorber Panel
Product Type: Absorber - Ceiling Panel - Interactive Absorber or Diffuser - Wall Panel
